The HitchCrafter 34K Haulin' Head Unit with Bolt-On Plate is a low-profile 5th wheel hitch built for heavy towing and regular professional use. Rated to haul up to 34,000 lbs, this single-pivot Haulin' hitch gives you a straightforward bolt-on setup with a solid steel design that is easy to inspect, grease, and maintain.
The included 1/2" bolt plate uses an 8" × 13" bolt pattern, making this a good option for trucks or mounting systems already set up for this plate configuration. Four grease fittings keep the main moving points serviceable, with two fittings at the jaw pivot points and two at the lower pivot pins.
34K Haulin' 5th Wheel Hitch Features
- Up to 34,000 lb hitch capacity
- Low-profile single-pivot design
- 1/2" bolt-on mounting plate
- 8" × 13" bolt pattern
- Four grease fittings for straightforward maintenance
- Solid steel Haulin' construction
- 100 lb hitch weight
- 18 × 18 × 8 in dimensions
- Made in the USA
Built for Heavy Towing and Professional Hauling
HitchCrafter's 34K Haulin' hitches are designed to haul up to 34,000 lbs, making them a strong fit for heavier towing applications when the truck and the rest of the towing setup are rated for the load.
The single-pivot design allows front-to-back movement and is commonly used for car hauling, hot shot work, and other larger trailers. If that matches the kind of work your truck does, the 34K Haulin' gives you a simple, heavy-duty hitch without adding unnecessary complexity.
Bolt-On Plate for a Straightforward Mounting Setup
This version of the 34K Haulin' Head Unit comes with a 1/2" bolt plate. The plate uses an 8" × 13" bolt pattern, so it can be matched to the correct mounting setup for your truck or platform.
Four Grease Points for Easy Maintenance
The 34K Haulin' uses four grease fittings to keep the main pivot points maintained. Two are located on top of the hitch at the jaw pivot points, and two are located at the lower front of the hitch for the side pivot pins.
HitchCrafter designed the Haulin' line around solid steel construction and accessible grease points, so routine cleaning and maintenance stay simple even when the hitch sees regular use.
Is a 34K 5th Wheel Hitch Right for Your Truck?
A 34,000 lb fifth wheel hitch does not mean every truck can safely tow 34,000 lbs. Your truck's towing capacity, chassis, tires, condition, trailer, license requirements, and other equipment all affect the amount you can actually tow.
If you are not sure whether this head unit, a complete bolt-on kit, or another mounting system is right for your truck, start with our
5th wheel hitches or give HitchCrafter a call at
(336) 859-3257.
34K Haulin' Head Unit With Bolt-On Plate Specs
| Specification |
Details |
| Product |
34K Haulin' Head Unit With Bolt-On Plate |
| Hitch Capacity |
Up to 34,000 lbs |
| Hitch Style |
Low-profile single pivot |
| Bolt Plate Thickness |
1/2" |
| Bolt Pattern |
8" × 13" |
| Grease Fittings |
4 |
| Weight |
100 lbs |
| Dimensions |
18 × 18 × 8 in |
